Parts List - M300

1	1001	Horizontal Bearing Block	$58.50
2	1002	Main Horizontal Slide	78.50
3	1003	Club Clamp	98.00
4	1004	Linear Bearing Block	83.00
5	1035	Face Angle Pivot Block 1/2" pin spacing	41.00
6	1006	Compression Clamp/2 dowel pins	29.00
7	1007	Loft Swivel Mount/pointer	37.00
8	1008	Face Angle Square/2 dowel pins	39.50
9	1009	Loft Plate	71.00
10	1010	Lie Bar	39.00
11	1011	Lie Pointer Assembly	24.00
12	1012	Slide Cover Plate	24.00
13	1013	Face Angle Plate	66.00
14	1015	Lie Plate	110.00
16	1029	Guideway Holder	26.00
17	1031	Linear Bearing Block Rods (Pair)	34.00
18	1039	Club Clamp and Lie Knob (same part)	5.50
19	1030	Main Slide Rods	29.00
20	1028	5/16 Stud included with 1002	2.10
21	1022	3/8"X 21/4" Dowel Pin	2.10
22	1021	Base Plate	230.00
23	1038	Vertical Adjustment Knob	4.82
24	1040	Linear Bearings--each	25.00
25	1032	Lie Bar Pivot Dowel 2"X 3/8"	2.10
26	1042	Loft Pivot Dowel Pin 3/8"X 3"	2.60
27	1033	Clamp ring 3/8"	4.25
28	1034	Setting Rod 3/8"	4.00
29	1037	Club Clamp Spring	4.25
30	1036	Linear Bearing Block Spring	4.25
31	1044	Precision Washers	5.50
32	1045	Lie Clamp Washer	1.50
33	1041	Face Angle Pivot Screw	3.50
34	1043	Lie Clamp Stud	2.50
